GPT7MQL8 GPT SINGLE SCREW PUMPS
Model: GPT7MQL8
General Type Single Screw Pumps are powerful industrial transportation tools. Their unique structure enables application in diverse working conditions. They can convey high - viscosity, particle - laden, and corrosive media. These pumps offer stable flow rates, flexible adjustment, low energy consumption, and are easy to install and operate. They effectively address transportation issues in industries like chemical engineering, sewage treatment, and food processing, making them an ideal choice for cost - cutting and efficiency - boosting
● Transportation of high - viscosity media: The viscosity of the media ranges from 20,000 to 200,000 MPa·s, depending on the size of the pump.
● Transportation of media containing solid particles or fibers: The maximum particle size is 16 mm, the longest fiber length is 100 mm. The solid - phase content is generally 40%, and when the solid in the media is in powder form, it can reach 60% or even higher.
● Continuous and stable transportation: There is no periodic pressure fluctuation like that of reciprocating pumps.
● Low - agitation transportation: It does not damage the inherent structure of the media.
● Satisfying low - noise requirements.
Structure Diagrams of Single - screw Pump
1.Discharge body 2.Tie rod 3.Stator 4.Screw shaft 5.Universal joint assembly 6.Feed body 7.Connecting shaft 8.Seal seat 9.Packing gland 10.Bearing housing 11.Bearing 12.Drive shaft13.Bearing cover 14.Coupling 15.Base 16.Motor
1.Motor 2.Gearbox 3.Bearing frame component 4.Packing seal component 5.Extension shaft 6.Universal joint component 7.Suction chamber 8.Connecting rod 9.Stator 10.Rotor 11.Tie rod 12.Base 13.Support feet 14.Discharge body
1.Motor 2.Gearbox 3.Direct-connection support 4.Extension shaft 5.Mechanical seal assembly 6.Connecting rod 7.Suction chamber 8.Universal joint assembly 9.Stator 10.Rotor 11.Tie rod 12.Base 13.Support feet 14.Discharge body
Application Fields
● Environmental protection field: Suitable for transporting industrial and domestic sewage, as well as sludge - laden turbid water containing solid particles and short fibers.
● Shipbuilding industry: Used for ship bottom cleaning and transporting media such as oil - water mixtures, oil sludge, and oily sewage.
● Petroleum industry: Transports crude oil, oil - water mixtures, and coalbed methane - water mixtures.
● Pharmaceutical and daily chemical industry: Can convey various viscous slurries, emulsions, and ointment - type cosmetics.
● Food canning industry: Can transport viscous starches, edible oils, honey, jams, and creams.
● Brewing industry: Suitable for transporting fermented viscous slurries, thick distiller's grains, residues of food products, and mucous liquids with various solid lumps.
● Construction industry: Used for spraying and transporting pasty substances like cement mortar, lime mortar, and coatings.
● Mining industry: Drains groundwater and slurry - laden sewage containing solid particles in mines to the ground.
● Chemical industry: The helical pump transports various suspensions, oils, colloidal slurries, and adhesives.
● Printing and paper - making industry: Can convey high - viscosity inks and PVC plastic pastes for wallpaper.
● Industrial boilers and power plants: The spiral pump is used for transporting coal - water slurry.
Performance Parameter Tables
| NO | Pump Model | Flow m³/h | Pressure MPa | Rated Speed rpm | Motor Power kW | nlet Diameter mm | Outlet Caliber mm | Function |
| 1 | GPT10-1-V | 0.1 | 0.6 | 960 | 0.55 | 25 | 25 | transport PAM |
| 2 | GPT13-1-V | 0.4 | 0.6 | 960 | 0.55 | 25 | 25 | transport PAM |
| 3 | GPT15-1-V | 0.6 | 0.6 | 960 | 0.75 | 25 | 25 | transport PAM |
| 4 | GPT20-1-V | 0.8 | 0.6 | 960 | 0.75 | 25 | 25 | transport PAM |
| 5 | GPT25-1-V | 2 | 0.6 | 960 | 1.5 | 32 | 25 | Transport sludge |
| 6 | GPT30-1-V | 5 | 0.6 | 960 | 2.2 | 50 | 40 | Transport sludge |
| 7 | GPT35-1-V | 8 | 0.6 | 960 | 3 | 65 | 50 | Transport sludge |
| 8 | TPG40-1-V | 12 | 0.6 | 960 | 4 | 80 | 65 | Transport sludge |
| 9 | GPT50-1-V | 20 | 0.6 | 960 | 5.5 | 100 | 80 | Transport sludge |
| 10 | GPT60-1-V | 30 | 0.6 | 960 | 11 | 125 | 100 | Transport sludge |
Selection of TPG-type pump with 8-pole motor(Low-voltage first -stage sludge inlet pump)
| NO | Pump Model | Flow m³/h | Pressure MPa | Rated Speed rpm | Motor Power kW | Inlet Diameter mm | Outlet Caliber mm | Function |
| 1 | GPT10-1-V | 0.08 | 0.6 | 720 | 0.55 | 25 | 25 | transport PAM |
| 2 | GPT13-1-V | 0.3 | 0.6 | 720 | 0.55 | 25 | 25 | transport PAM |
| 3 | GPT15-1-V | 0.45 | 0.6 | 720 | 0.55 | 25 | 25 | transport PAM |
| 4 | GPT20-1-V | 0.6 | 0.6 | 720 | 0.55 | 25 | 25 | transport PAM |
| 5 | GPT25-1-V | 1.5 | 0.6 | 720 | 1.1 | 32 | 25 | Transport sludge |
| 6 | GPT30-1-V | 4 | 0.6 | 720 | 2.2 | 50 | 40 | Transport sludge |
| 7 | GPT35-1-V | 6 | 0.6 | 720 | 2.2 | 65 | 50 | Transport sludge |
| 8 | GPT40-1-V | 9 | 0.6 | 720 | 3 | 80 | 65 | Transport sludge |
| 9 | GPT50-1-V | 15 | 0.6 | 720 | 4 | 100 | 80 | Transport sludge |
| 10 | GPT60-1-V | 25 | 0.6 | 720 | 7.5 | 125 | 100 | Transport sludge |
| 11 | GPT70-1-V | 40 | 0.6 | 720 | 11 | 150 | 125 | Transport sludge |
| 12 | GPT85-1-V | 50 | 0.6 | 720 | 15 | 150 | 150 | Transport sludge |
Selection of TPG-type pump with 6-pole motor(Low-voltage second -stage sludge inlet pump)
| NO | Pump Mode | Flow m³/h | Pressure MPa | Rated Speed rpm | Motor Power kW | nlet Diameter mm | Outlet Caliber mm | Function |
| 1 | GPT10-2-V | 0.1 | 1.2 | 960 | 0.55 | 25 | 25 | transport PAM |
| 2 | GPT13-2-V | 0.4 | 1.2 | 960 | 1.1 | 25 | 25 | transport PAM |
| 3 | GPT15-2-V | 0.6 | 1.2 | 960 | 1.1 | 25 | 25 | transport PAM |
| 4 | GPT20-2-V | 0.8 | 1.2 | 960 | 1.5 | 25 | 25 | transport PAM |
| 5 | GPT25-2-V | 2 | 1.2 | 960 | 2.2 | 32 | 25 | Transport sludge |
| 6 | GPT30-2-V | 5 | 1.2 | 960 | 3 | 50 | 40 | Transport sludge |
| 7 | GPT35-2-V | 8 | 1.2 | 960 | 4 | 65 | 50 | Transport sludge |
| 8 | GPT40-2-V | 12 | 1.2 | 960 | 5.5 | 80 | 65 | Transport sludge |
| 9 | GPT50-2-V | 20 | 1.2 | 960 | 7.5 | 100 | 80 | Transport sludge |
| 10 | GPT60-2-V | 30 | 1.2 | 960 | 15 | 125 | 100 | Transport sludge |
Selection of TPG-type pump with 8-pole motor(Low-voltage second -stage sludge inlet pump)
| NO. | Pump Model | Flow m³/h | Pressure MPa | Rated Speed rpm | Motor Power kW | Inlet Diameter mm | Outlet Caliber mm | Function |
| 1 | GPT10-2-V | 0.08 | 1.2 | 720 | 0.55 | 25 | 25 | transport PAM |
| 2 | GPT13-2-V | 0.3 | 1.2 | 720 | 0.75 | 25 | 25 | transport PAM |
| 3 | GPT15-2-V | 0.45 | 1.2 | 720 | 1.1 | 25 | 25 | transport PAM |
| 4 | GPT20-2-V | 0.6 | 1.2 | 720 | 1.1 | 25 | 25 | transport PAM |
| 5 | GPT25-2-V | 1.5 | 1.2 | 720 | 1.5 | 32 | 25 | Transport sludge |
| 6 | GPT30-2-V | 4 | 1.2 | 720 | 2.2 | 50 | 40 | Transport sludge |
| 7 | GPT35-2-V | 6 | 1.2 | 720 | 3 | 65 | 50 | Transport sludge |
| 8 | GPT40-2-V | 9 | 1.2 | 720 | 4 | 80 | 65 | Transport sludge |
| 9 | GPT50-2-V | 15 | 1.2 | 720 | 7.5 | 100 | 80 | Transport sludge |
| 10 | GPT60-2-V | 25 | 1.2 | 720 | 11 | 125 | 100 | Transport sludge |
| 11 | GPT70-2-V | 40 | 1.2 | 720 | 18.5 | 150 | 125 | Transport sludge |
Selection of TPG-type pump with 6-pole motor(High -voltage second -stage sludge inlet pump)
| NO. | Pump Model | Flow m³/h | Pressure MPa | Rated Speed rpm | Motor Power kW | Inlet Diameter mm | Outlet Caliber mm | Function |
| 1 | GPT10-2-V | 0.1 | 1.2 | 960 | 0.55 | 25 | 25 | transport PAM |
| 2 | GPT13-2-V | 0.4 | 1.2 | 960 | 1.1 | 25 | 25 | transport PAM |
| 3 | GPT15-2-V | 0.6 | 1.2 | 960 | 1.1 | 25 | 25 | transport PAM |
| 4 | GPT20-2-V | 0.8 | 1.2 | 960 | 1.5 | 25 | 25 | transport PAM |
| 5 | GPT25-2-V | 2 | 1.2 | 960 | 2.2 | 32 | 25 | Transport sludge |
| 6 | GPT30-2-V | 5 | 1.2 | 960 | 3 | 50 | 40 | Transport sudge |
| 7 | GPT35-2-V | 8 | 1.2 | 960 | 4 | 65 | 50 | Transport sludge |
| 8 | GPT40-2-V | 12 | 1.2 | 960 | 5.5 | 80 | 65 | Transport sludge |
| 9 | GPT50-2-V | 20 | 1.2 | 960 | 7.5 | 100 | 80 | Transport sludge |
| 10 | GPT60-2-V | 30 | 1.2 | 960 | 15 | 125 | 100 | Transport sludge |
Selection of TPG-type pump with 8-pole motor(High -voltage second-stage sludge inlet pump)
| NO | Pump Model | Flow m³/h | Pressure MPa | Rated Speed rpm | Motor Power kW | Inlet Diameter mm | Outlet Caliber mm | Function |
| 1 | GPT10-2-V | 0.08 | 1.2 | 720 | 0.55 | 25 | 25 | transport PAM |
| 2 | GPT13-2-V | 0.3 | 1.2 | 720 | 0.75 | 25 | 25 | transport PAM |
| 3 | GPT15-2-V | 0.45 | 1.2 | 720 | 1.1 | 25 | 25 | transport PAM |
| 4 | GPT20-2-V | 0.6 | 1.2 | 720 | 1.1 | 25 | 25 | Transport sludge |
| 5 | GPT25-2-V | 1.5 | 1.2 | 720 | 1.5 | 32 | 25 | Transport sludge |
| 6 | GPT30-2-V | 4 | 1.2 | 720 | 2.2 | 50 | 40 | Transport sludge |
| 7 | GPT35-2-V | 6 | 1.2 | 720 | 3 | 65 | 50 | Transport sludge |
| 8 | GPT40-2-V | 9 | 1.2 | 720 | 4 | 80 | 65 | Transport sludge |
| 9 | GPT50-2-V | 15 | 1.2 | 720 | 7.5 | 100 | 80 | Transport sludge |
| 10 | GPT60-2-V | 25 | 1.2 | 720 | 11 | 125 | 100 | Transport sludge |
| 11 | GPT70-2-V | 40 | 1.2 | 720 | 18.5 | 150 | 125 | Transport sludge |
