TIPA6W9MQL Temperature Controller High Centrifugal Pumps
Model:TIPA6W9MQL
Temperature Controller High Centrifugal Pumps For Heat Preservation for Heat Preservation, the innovative upgrade from chemical pumps, are crafted by Omron Tech Pumps. The pumps in Omron Tech Pumps series feature ingenious designs. Their hollow sandwich structure is compatible with a variety of insulating media, enabling precise temperature control, ensuring efficient and stable transportation, and demonstrating excellent performance under complex working conditions, thus facilitating the smooth operation of chemical production processes. We adhere to the principle of putting customers first, providing professional selection advice and customized services, making every effort to maintain equipment stability. Our prices are also highly competitive, allowing you to obtain high - quality products at an affordable cost.
● Insulated Pump Body: Combines with the insulated pump cover to maintain a constant temperature and is supported by feet.
● Impeller: Closed type. Axial force is balanced by balance holes or auxiliary vanes, and the remaining force is borne by the bearings.
● Insulated Pump Cover: Forms a standard seal chamber with the insulated seal gland, maintaining a constant temperature and being compatible with various seals.
● Shaft Seal: Depending on the working conditions, packing, single and double end face, and tandem mechanical seals can be selected.
● Bearings: Lubricated with thin oil. The constant level oil cup controls the oil level to ensure good lubrication.
● Shaft: Protected by a shaft sleeve to prevent corrosion and extend the service life.
● Rear-supported Design: Protected by a shaft sleeve to prevent corrosion and extend the service life.
TIP Centrifugal Pump Diagram
Application Areas
● Petrochemical Industry: Transportation of high-temperature crude oil, heavy oil circulation, and asphalt insulation.
● Fine Chemical Industry: Constant-temperature transportation of molten sulfur and liquid phenolic resin.
● Pharmaceutical Field: Aseptic insulation transportation of heat-sensitive APIs and syrup-like media.
● Sugar Industry: Used for the transportation of syrup, sugar paste, and molasses.
● Power Plants: For the transportation of boiler feed water, condensate water, and desulfurization and denitrification slurries.
● Paper Mills: For the transportation of high-temperature pulp, coating liquid, and white water.
Working Conditions
● Flow Rate: 2 - 2000m³/h
● Head: Up to 160m
● Pressure: ≤2.5MPa
● Temperature: - 40℃ - 260℃
● Rotation Speed: 1450rpm/min, 2950rpm/min
