TIP8C2XKWR Horizontal Centrifugal Pumps

Product Description

TIP Horizontal Centrifugal PUMPS, the Omron Tech Pumps TIP series, as horizontal single - stage single - suction centrifugal pumps, are remarkable in many aspects. They have a compact design, which makes installation and maintenance convenient. The pump body adopts a foot - supported structure, ensuring high stability. The impeller is of a closed - type design, featuring high efficiency, high head, wide application range, and stable operation. Depending on different working conditions, the shaft seal can take the form of packing seal, single - end - face mechanical seal, double - end - face mechanical seal, or tandem mechanical seal. Thanks to the back - pull - out design, it is very convenient to carry out maintenance without adjusting the inlet and outlet pipelines of the pump.

Schematic Diagram of the TIP Series

Application Areas

● Petrochemical Industry: During the oil refining process, it is responsible for transporting crude oil, petroleum products, and various chemical additives. In chemical synthesis processes, it undertakes the transportation of reaction raw materials and intermediate products.

● Fine Chemical Industry: It is suitable for the transportation of high - precision, small - flow, and high - purity chemical raw materials and products during the production of fine chemical products such as pharmaceuticals, pesticides, and fragrances.

● Sugar Industry: From the rapid extraction during raw material processing to the purification and evaporation stages, it accurately transports sugar liquid to various key equipment. Additionally, in the cyclic transportation of production water, it comprehensively guarantees the stable and efficient operation of sugar refineries.

● Paper Industry: It transports the well - mixed pulp raw materials to the headbox of the paper machine, ensuring a stable and continuous supply of pulp, which lays the foundation for paper formation.

● Power Generation Industry: In the cooling system, industrial process pumps transport a large amount of circulating water to equipment such as condensers. This process can remove the heat from the steam discharged by the steam turbine, ensuring the efficient operation of the equipment.

Main Features

● Strictly designed and manufactured in accordance with the API OH1 international standard, the product's quality and performance reach the international advanced level.

● The pump cover and the seal gland form a sealing chamber. This chamber has standard dimensions and can be adapted to various sealing types.

● The bearings are lubricated with thin oil, and the oil level is precisely controlled by a constant - level oil cup to fully ensure that the bearings are always operating under good lubrication conditions.

● The shaft is protected by a shaft sleeve to prevent corrosion caused by direct contact between the medium and the shaft, thereby effectively extending the service life of the shaft.

● According to the characteristics of different chemical media, multiple material options are provided to meet diverse requirements for corrosion resistance and wear resistance.

● The TIP horizontal centrifugal pump adopts a standardized design. Its components have strong universality, which facilitates maintenance and replacement, effectively reducing maintenance costs and downtime.

● It is easy to install, operate, and maintain, reducing the technical threshold for operators and improving production efficiency.

Operating Conditions

● Flow Rate: 2 m³/h - 2000 m³/h

● Head: Up to 160 m

● Pressure: Up to 2.5 MPa

● Temperature: - 40°C - 260°C

● Rotation Speed: 2960 r/min, 1480 r/min
